Server Technology PRO2 Switched PDU C2W42CE-YCMFAM00 - Power distribution unit (rack-mountable) - AC 208 V - 8.6 kW - 3-phase WYE (star) - Ethernet 10/100, RS-232 - input: NEMA L21-30P - output connectors: 42 (power IEC 60320 C13)

The Server Technology PRO2 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO2 Switched "Master" PDU can be connected to as many as three (with optional module) PRO2 Switched "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.

• High-density outlet technology
• Network monitoring
• Temperature/humidity monitoring
• Auto-flip current display
• Per-Inlet Power Sensing (PIPS)
• Branch current monitoring
• Branch circuit protection
• Alternating-phase outlets
• High retention locking outlets
• Flexible mounting
